2 HP 4 Stage Openwell Pump

Get a Price/Quote

MOQ : 1 Unit

2 HP 4 Stage Openwell Pump Specification

Flow Rate
Up to 200 LPM

Caliber
Standard

Speed
2900 RPM

Control System
Manual/Starter Control

Discharge Pressure
Up to 3.2 kg/cm2

Features
Thermal Overload Protection, Rust-Resistant, Energy Efficient

Frequency
50 Hz

Mounting Type
Horizontal/Vertical

Max Suction
Openwell (Submerged Installation)

Voltage
220-240 V AC, Single Phase

Noise Level
Low

Theory
Centrifugal Pump

Working Temperature
Up to 60C

Inlet/Outlet
32 mm / 32 mm (1.25 / 1.25) Approx.

Head Size
Up to 32 meters

Material
Stainless Steel & Cast Iron

Structure
Vertical Multistage

Power
2 HP

Standard
ISI Marked / as per IS:14220

Fuel Type
Electric

Pressure
Medium

Usage
Agriculture, Irrigation, Domestic Water Supply

Application
Openwell Water Pumping

Suction Type
Openwell/ Submersible

Seals Type
Mechanical Seal

Priming
Self Priming Not Required (Submerged)

Pump Type
Openwell Submersible Pump

Capacity
Up to 15 m3/hr

Minimum Water Depth Required
1.5 feet

Cooling Type
Water Cooled

Service Factor
1.0

Protection Grade
IP 68

Insulation Class
B or F

Impeller type
Multistage Diffuser

2 HP 4 Stage Openwell Pump Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About 2 HP 4 Stage Openwell Pump

Introducing the must-have 2 HP 4 Stage Openwell Pump-renowned for its champion performance and valorous reliability. Crafted with a stainless steel and cast iron standard caliber body, this vertical multistage pump is engineered for agricultural, irrigation, and domestic water supply. Featured with a special rate of energy efficiency, the pump runs on 220-240 V AC single-phase power, supporting up to 32 meters head size and 200 LPM flow rate. With thermal overload protection, rust-resistant materials, low noise level, and ISI certification, it is the trusted choice for dealers and suppliers across India.

Superior Application, Features & Design

The 2 HP 4 Stage Openwell Pump is ideal for agricultural fields, irrigation systems, and home water supply. Its champion multi-stage diffuser impeller delivers steady flow up to 200 LPM, while IP68 protection and balanced stainless steel/cast iron construction ensure durability. Featuring thermal overload protection, rust-resistance, and a user-friendly manual/starter control system, this pump excels in submerged installation and promises a renowned performance with medium pressure and high reliability.

Certified Excellence & Supply Capabilities

Certified as ISI Marked and conforming to IS:14220 standards, the 2 HP 4 Stage Openwell Pump comes with assured authenticity. Dealers benefit from strong supply ability across India, and express shipping options are available to reduce expenditure and streamline your outlay. For eligible bulk orders, sample pumps can be provided, ensuring customer satisfaction and trust before full commitment.

FAQ's of 2 HP 4 Stage Openwell Pump:

Q: How does the 2 HP 4 Stage Openwell Pump benefit agricultural and irrigation applications?

A: The pump offers reliable, high-volume water delivery with a flow rate up to 200 LPM and a head height of up to 32 meters, making it perfect for wide-ranging agricultural and irrigation needs.

Q: What protection features are included in this pump for enhanced durability?

A: This pump is equipped with IP68 water ingress protection, rust-resistant materials, thermal overload protection, and a mechanical seal, ensuring prolonged and valorous service life.

Q: Where can the 2 HP 4 Stage Openwell Pump be installed?

A: It is designed for openwell or submersible installations, allowing flexibility in agricultural fields, domestic water tanks, and irrigation wells with a minimum depth of 1.5 feet.

Q: What is the process to avail express shipping or request a product sample?

A: Customers and dealers can reach out to the supplier directly to discuss outlay details, arrange express shipping, or request a sample-streamlining procurement and supporting informed purchasing decisions.

Q: How energy efficient is the 2 HP 4 Stage Openwell Pump?

A: Thanks to its innovative multistage design and energy-efficient motor, the pump minimizes energy expenditure while delivering reliable performance, making it a cost-effective choice in the long term.
